Product Overview
This T5 LED tube light is a 600mm (approximately 2 feet) long, integrated lighting solution designed to replace traditional fluorescent lamps. It is engineered for high energy efficiency, superior brightness, and a long lifespan, making it an ideal choice for various indoor applications such as homes, offices, warehouses, and retail spaces. The product features an integrated design, meaning the LED driver is built-in, which often simplifies installation.
Key Features
- Energy Saving: Consumes significantly less power compared to traditional fluorescent T5 tubes, potentially saving up to 50% or more on energy costs.
- Super Bright: Utilizes high-lumen LED chips to provide clear and bright illumination.
- Long Lifespan: Rated for up to 30,000 hours of use, reducing the frequency and cost of replacements.
- Integrated Design: The built-in driver (for integrated models) allows for easier retrofitting in some fixtures.
- High Color Rendering Index (CRI): With a CRI of 80, it renders colors more accurately and naturally, which is crucial for retail and office environments.
- Instant Start: Lights up immediately without flickering or warm-up time.
- Eco-Friendly: Contains no mercury or other hazardous materials, making it safer for the environment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | T5 |
| Tube Length | 600mm (2ft) |
| Power (Wattage) | Typically ranges from 8W to 12W for 600mm models, replacing 14W-20W traditional T5 lamps. |
| Luminous Flux | Varies by model; high-efficiency models can achieve over 100 lm/W. |
| Color Temperature (CCT) | Commonly available in Cool White (6000-6500K), Neutral White (4000-4500K), and Warm White (2700-3000K). |
| Color Rendering Index (CRI) | >80 (as per product attribute) |
| Base Type | G5 (bi-pin base for T5 lamps) |
| Input Voltage | AC 85V - 265V (wide voltage range for global compatibility) |
| Lifespan | Up to 30,000 hours |
| Warranty | 1 year (as per product attribute) |
Usage and Installation Guide
Important: Before installation, always turn off the power at the circuit breaker to prevent electric shock.
- Check Fixture Compatibility: Ensure your existing fixture is designed for T5 lamps and has a G5 socket. Determine if it uses an electronic ballast or is a direct-wire fixture.
-
Installation Types:
- Ballast-Bypass (Direct Wire) Installation: For integrated LED tubes, the internal driver requires direct AC power. This often involves removing or bypassing the existing fluorescent ballast and wiring the AC power directly to the lamp holders. Consult a qualified electrician if you are unsure.
- Ballast-Compatible Installation: Some LED tubes are designed to work with existing electronic ballasts. Verify the product specifications to confirm compatibility.
- Mounting: Remove the old fluorescent tube. Align the pins of the T5 LED tube with the slots in the lamp holders, gently push in, and rotate 90 degrees until it clicks into place.
-
Applications: This T5 LED tube is suitable for a wide range of indoor settings, including:
- Office lighting
- Supermarket and retail shelf lighting
- Warehouse and industrial lighting
- School and hospital lighting
- Home kitchens, garages, and basements
Buying Guide and Considerations
- Determine Required Brightness: Consider the lumen output rather than just wattage. Higher lumens mean a brighter light.
- Choose the Right Color Temperature: Select a color temperature that suits the atmosphere of the space (e.g., Cool White for task lighting, Warm White for relaxing areas).
- Check Installation Type: Confirm whether you need a ballast-bypass or ballast-compatible tube to match your existing fixtures.
- Verify Certifications: Look for safety certifications like CCC, CE, or RoHS to ensure product quality and compliance with standards.
- Compare Prices and Suppliers: On platforms like 6688789, compare prices from different suppliers and check their store ratings and customer reviews.
After-Sales Service and Warranty
The product comes with a 1-year warranty from the supplier, Shenzhen Pute Optoelectronic Technology Co., Ltd. In case of product defects under normal use during the warranty period, buyers can typically contact the supplier for a replacement or repair. It is advisable to:
- Keep the original packaging and invoice as proof of purchase.
- Contact the supplier directly through the 6688789 platform to initiate a dispute or claim if necessary.
- Understand the specific warranty terms provided by the supplier before purchasing.
