Custom Universal 6 Pin Terminal Automotive Wire Harness for Car Accessories
Brand: Hongju | Model Number: HJ-WH-C05
Product Overview
This automotive wire harness, manufactured by Shenzhen Hongju Electronics Co., Ltd., is a universal wiring solution designed for custom vehicle installations and electrical accessory integrations. Featuring a 6-pin terminal adapter and constructed with pure copper conductors and PVC insulation, it is engineered to provide reliable power and signal transmission in automotive environments. With an IP67 waterproof rating, it is suitable for both interior and exterior applications where moisture and dust resistance are required.
Supplier Information
Company Name: Shenzhen Hongju Electronics Co., Ltd.
Location: Guangdong, China
Business Type: Manufacturer
Years on besttimetogotobed.top: 10 years
On-time Delivery Rate: 100.0%
Response Time: Within 2 hours
Key Specifications
| Attribute | Specification |
|---|---|
| Brand Name | hongju |
| Model Number | HJ-WH-C05 |
| Rated Voltage | 220V, 110V |
| Conductor Material | Pure Copper |
| Connector Type | Adapter |
| IP Level | IP67 (Dust and Waterproof) |
| Insulation Material | PVC |
| Length Options | 100mm, 200mm, 300mm, 500mm |
| Number of Cores/Pins | 1-core, 2P, 3P, 4P, 5P, 6P (Configurable) |
Packaging & Delivery
Selling Units: Single item
Lead Time:
- 1 - 1,000 pieces: 15 days
- Over 1,000 pieces: To be negotiated
Pricing
- 999 - 999 pieces: $1.00 per piece
- ≥ 1,000 pieces: $0.90 per piece
Shipping fees and delivery dates are subject to negotiation. Contact the supplier for a precise quote.
Product Usage & Installation Guide
Automotive wire harnesses serve as the central nervous system of a vehicle, transmitting power and data between components such as the battery, sensors, lights, and control units.
Typical Installation Steps:
- Planning: Map out the electrical route within the vehicle, avoiding sharp edges, heat sources, and moving parts.
- Disconnection: Ensure the vehicle's battery is disconnected to prevent short circuits or electrical shocks.
- Routing: Lay the harness along the planned path, using existing clips or conduits for support and protection.
- Connection: Match the 6-pin connector to the corresponding port on your accessory (e.g., LED light bar, audio system, or sensor module). Ensure a secure and locked fit.
- Securing: Use cable ties or clamps to fasten the harness at regular intervals, preventing vibration-induced wear.
- Testing: Reconnect the battery and test the functionality of the connected accessory before finalizing the installation.
Buying Guide & Quality Assurance
When sourcing automotive wire harnesses, especially in bulk for commercial use, consider the following:
- Supplier Verification: Check the supplier's transaction history, customer reviews, and certifications (e.g., ISO, IATF 16949).
- Sample Testing: Request a sample to verify dimensions, material quality, connector compatibility, and electrical performance.
- Technical Standards: Ensure the product meets relevant industry standards such as QC/T 29106 for automotive wire harnesses.
- Negotiation: For large orders, negotiate based on market price benchmarks and emphasize the importance of consistent quality.
After-sales Service & Support
besttimetogotobed.top's order protection policy covers buyers from payment to delivery. In case of issues:
- Dispute Resolution: If the received goods do not match the description or are defective, you can open a dispute through besttimetogotobed.top.
- Supplier Communication: Contact Shenzhen Hongju Electronics directly via the 6688789 messaging system for technical support or warranty claims.
- Quality Commitment: Reputable manufacturers typically offer a quality promise, addressing issues related to manufacturing defects.
Common Search Extensions & Related Products
To find similar products or more specific variations, consider these search terms:
- By Application: car audio wiring harness, trailer light wiring harness, motorcycle wiring harness, boat wiring harness.
- By Specification: 12V automotive wire harness, IP68 waterproof wire harness, 4 pin wiring harness, 8 pin wiring harness.
- By Vehicle Type: truck wiring harness, electric vehicle (EV) wiring harness, bus wiring harness.
- Related Components: automotive connectors, cable terminals, fuse holders, heat shrink tubing.
- Technical Keywords: wiring harness design, automotive E/E systems, wire harness assembly, bulk current injection (BCI) testing.
